Product Description

Airplane and Heli mode,

Stored and unstored Governor, external governor.

Data Logging, Data output port for external data logging device, such as Mikado V control / Vbar combinations. Jeti Telemetry , JLog 3 ( more compatible device will be added gradually like Futaba..etc.)

ESC setup can be set by Mikado V control Radio.

PC connectivity, Android connectivity ( OTG cable needed) , V link II Cable(optional) plus Diode adaptor(included) cable needed.

Supported HvLi battery 14S total 61V.

Size: 83.4 x 45 x 27.6 mm

Weight: 218 Grams.

Mikado Proving Ground Produced by Kyle Dahl

Bobby Watts show you how to set up the Tribunus 14-200A ESC and Demonstration flight by Kyle Stacy

Scorpion Tribunus II 14-200A - User Manual

** Scorpion Tribunus Heli Program Sproto

Scorpion V Link II Cable CH340 Driver (For all ESC use)

How to DIY your own Telemetry/setup cable for the Tribunus ESCs – Vbar NEO

How to DIY your own Telemetry/setup cable for the Tribunus ESCs – Jeti

DIY your spark suppressor system on a ESC

How-to update Tribunus firmware

Specifications

Max Continuous Current	200 Amps
Peak Current	250Amps
Operating Voltage Range	14-61 Volts
BEC Output voltage:	5.1V to 8.3V adjustable.
Max Continuous BEC Output	10 Amps @ 8.3 V
Peak BEC Output	20 Amps/1s @ 8.3 V
On Resistance	055 mOhms *2
Size	83.4 x 45 x 27.6 mm (3.28 x 1.77 x 1.08 in)
